Storage Counter
Constructed of AISI304 Food Grade Stainless Steel. Top Panel 1.5mm Thick, Undershelves 1.2mm THK and Legs are also AISI304 and are Square Pipes 40x40x1.5mm THK with Nylon or Stainless Steel Adjustable Feet. The Top Panel is sound deadened with 32x32x3mm THK SS Angle Frame, while Undershelves are sound deadened with Omega Channel only. Side and Rear Panels are 1mm THK. Available with various configurations like, with or without Splash Guards, 1 or 2 under Shelves & openable or sliding doors depending upon the requirement. The Sliding doors are, made from 1.2mm THK stainless steel sheet with formed handles and are provided with locks. Standard length of the Storage Counters ranges from 500mm to 2900mm with an increment of 100mm in length, and Standard depth of the Storage Counters ranges from 500mm to 900mm with an increment of 100mm. Height of the Storage Counters are a standard 850mm and an additional 150mm Splash Guard if provided.
Heated Storage Counter
Constructed of AISI304 Food Grade Stainless Steel. Top Panel 1.5mm Thick, Undershelves are 1.2mm THK and Legs are also AISI304 and are Square Pipes 40x40x1.5mm THK with Nylon or Stainless Steel Adjustable Feet. The Top Panel is sound deadened with Angle Iron 32x32x3mm THK while Undershelves are sound deadened with Omega Channel of 1.2mm THK. Side and Rear Panels and the respective insulation panels are 1mm THK. Control Panel is provided with Rotary Switch, Analog Thermostat & Light Indicators. Available with various configurations like, with or without Splash Guards, 1 or 2 Under Shelves & 2 to 4 Sliding Doors with insulation depending upon the requirement. The Sliding doors are, made from 1.2mm THK stainless steel sheet with formed handles and are provided with locks. Standard length of the Heated Storage Counters ranges from 500mm to 2900mm with an increment of 100mm in length, and Standard depth of the Heated Storage Counters ranges from 500mm to 900mm with an increment of 100mm. Height of the Heated Storage Counters are a standard 850mm and an additional 150mm Splash Guard if provided.
Wall Mounted Storage Cabinet
Constructed of AISI304 Food Grade Stainless Steel. Top Panel and Bottom Panel are of 1.2mm THK. The Bottom Panels is sound deadened with Omega Channels of 1.2mm. Side and Rear Panels are 1mm THK. The Hanging Points are reinforced with 3mm THK Gusset Plates. Available with various configurations like, Open Type, with or without middle shelf & openable or sliding doors depending upon the requirement. Standard length of the Wall Mounted Storage Counters ranges from 500mm to 2900mm with an increment of 100mm in length, and Standard depth of the Wall Mounted Storage Counter is 300mm. Height of the Wall Mounted Storage Cabinet are a standard 450mm.
